1pc SSR Output REX-C100 Digital PID Temperature Control Controller Thermostat 0000 to 9999 Universal Input

Temperature ControllersREX-C100 Digital PID Temperature Control Controller Thermostat Relay output Features:Product model:REX-C100FK02-M*ANOutput:RELAYDimensions:about48mm×48mm×110mm(APP) Or 48mm×48mm×90mm(APP) Measuring accuracy: ±0.5%FSCold-end compensation tolerance: ±2 Celsius (can be modified by software in 0~50 Celsius )Resolution: 14 bit Sampling cycle: 0.5 SecProcess value (PV), Setting value (SV)Output, alarm and self-tuning can be indicated by: LEDPIN control (including ON/OFF, step-type PID and continuous PID)Self-tuning controlRelay output: contact capacity 250V AC 3A (resistive load)Alarm function output: 2 wayContact capacity of output: 250V AC 3A (resistive load)Setting value (SV): identical to measuring range (PV)Proportional band (P): 0~full range (ON/OFF control when set to 0)Detective temperature range:0 to 400 CelsiusInsulation resistance: >50M ohm(500V )Insulation resistance: 1500V AC/minPower Consumption: 10 VAService environment: 0~50 Celsius ,environment with no corrosive gas 30~85% RHSupply:weusually sell AC100V--240V 50/60HZ , AC220V 50/60HZ is also available. if you need AC220V, please make notes in your order. Indication for you: if your voltage is between 100V--240V like 110V or 240V , you'd better choose AC100V--240V 50/60HZ, if your voltage is 220V, you can use both AC100V--240V 50/60HZ and AC220V.
