RATTMMOTOR No powered Multi-function Lathe Chuck Spindle Assemblies 895 Motor Rotary Lathe Woodworking Spindle Motor Chuck 50mm for CNC Lathe Grinder machine Table Saw (3 Jaw 50mm)
$89.09
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by rosary.college
We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here.
$89.09
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by rosary.college
Free 30-day returns Details
Product details
| Management number | 210013380 | Release Date | 2026/04/02 | List Price | $35.64 | Model Number | 210013380 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- 【6000-12000RPM】No-load current 1.5A, turning force: 8KG/cm, torque: 0.78N.m, rated voltage 12-24V DC, motor speed up to 12000rpm, 12V/6000rpm, 24V/12000rpm, , supports forward and reverse, high speed, strong momentum.
- 【K01-63mm Self-centering Chuck】Jaw: 3 Jaw; Internal jaw clamping: 2-15mm; External jaw clamping: 20-50mm; Connection form: threaded connection, threaded port size: M14.
- 【XL10 teeth 5mm + XL30 teeth 15mm motor synchronous wheel】Aluminium alloy synchronous wheel, high transmission efficiency, and smooth transmission, with buffer, vibration damping capacity, low noise. Synchronous wheel reduction ratio 1:3.
- 【110XL belt】Circumference 279.44mm, number of teeth 55, transmission speed ratio range, compact structure suitable for multi-axis transmission, without lubrication; belt selection of high quality materials, anti-wear.
- 【Chuck Assembly Parts Overview】1*Chuck; 2*Chuck spanner; 1*Through-hole spindle rod; 1*Spindle bearing housing; 1*XL10 tooth 5mm synchro wheel; 1*XL30 tooth synchro wheel; 1*XL110 belt; 3*Inner 6-angle spanner.
| Capacity | 50 Millimeters |
|---|---|
| Lock Type | Self Centering |
| Brand Name | RATTMMOTOR |
| Unit Count | 1.0 Count |
| Handle Type | hand-tightened |
| Thread Size | M14 |
| Manufacturer | RATTMMOTOR |
| Model Number | XIAOJ-50mm |
| Item Diameter | 50 Millimeters |
| Compatible Devices | Drilling Machine, Grinding Machine, Lathe, Milling Machine |
| Included Components | No powered Multi-function Lathe Chuck Spindle Assemblies 895 Motor |
| Manufacturer Part Number | 3JAW50-XIAOJ-HU |
